AB101 Digital Battery Tester 12V Portable Car Battery Monitor Car Cranking Charging Circuit Tester Auto Analyzer Vehicle
AB101 Digital Battery Tester 12V Portable Car Battery Monitor Car Cranking Charging Circuit Tester Auto Analyzer Vehicle
Couldn't load pickup availability
SPECIFICATIONS
12V Battery Tester range: CCA 100- 2000 CCA, 30- 220AH
Battery Coverage: Applied for Regular Flooded/AGM Flat Plate/GEL/AGM Spiral Battery
Battery Included: Yes
Certification: CE
DC Voltmeter test range: 8-16VDC
Item Name: AB101 12V Car Battery Tester
Language: English, French, Spanish, German, Italian, Russian
Screen: 2.0''Backlit LCD
Type: Vehicle Battery Tester
Highlights of car battery tester-AB101
①Battery health test ➤ It conducts a benchmark test on the battery and gives suggestions on whether to replace the battery. In addition, it also includes start-up and charging system testing.
②Wide range of testing ➤ AB101 battery tester is specially designed for most 12V batteries, such as ordinary flooded batteries, AGM flat batteries, AGM spiral batteries and gel batteries, and strictly follows the battery rating standards-CCA, BCI, CA, MCA, JIS, DIN, IEC, EN, SAE, GB.
③Start test and charging test ➤It will display the test result within 5 seconds. The 12V charging system is fully inspected to ensure that the generator output is normal, the rectifier diode is working normally, and the charging current is controlled.
④Unparalleled user experience ➤ Lighter, durable, and menu-based operation; even beginners can easily use this car battery tester.
⑤ Switch between 6 languages at will ➤ English, Russian, Spanish, French, German, Italian.
AB101, Car Battery Health Guard!
➤CCA: 100~2000 CCA
➤Battery Test: The car battery analyzer shows 5 different results: “Good Battery”, “Good-Recharge”, “Replace”, “Bad Cell- Replace”, “Charge-Retest”.
➤Charging Test: The battery tester checks ripple status, load voltage, and charging system status.
➤Cranking Test: The battery is regarded as OK if cranking voltage is higher than 9.6V or abnormal if lower than 9.6V.
➤Ripple Test: The load tester tests the charging current ripple to find out whether the diode is normal or not.
➤In-Vehicle or Out-Of-Vehicle: No matter whether the battery is connected to the vehicle or not, the battery tester can test it directly.
➤No Need to Charge or Update: The auto battery tester will automatically start up after the clamps are correctly connected. Without the needs of any software updates.
Run multi-test in one button
Auto Battery Test + Cranking Test + Charging Test + State of Health +State of Charge + Ripple Analysis
Start test data overall status
Cranking test to know the whole state of the starting system according to the data.
TOPDON PK KONNWEI，AUTOOL，A
Cranking & charging test
5 test results, no prior knowledge
Multiple languages
For English, Spanish, French, German, Russian, Italian.
Easy to carry
Small and exquisite
Attention on AB101
➤If the clamps are stably clutched?--Confirm the clamp connection
➤If the battery terminal conduct normally?--Check if the terminals rusts
➤If the battery has a low battery?--Charge your vehicle battery
➤If temperature is too low?--The result will be inaccurate when the temperature is below 14°F (-10°C)
➤If there is a strong magnetic force? --Remove the stuff with a strong magnetic force
Incompatible Problems
➤If the voltage range is beyond the product? --Check the voltage range of your battery and the products
LCD Display
➤Low voltage of your battery--Charge your vehicle battery
